BIGGER. tougher.
apex-LINE
4x4 / 6x6
BUILD STANDARD
Comfort and power to take you through wilderness adventures.
20' 4-seasons fully insulated total-composite box with cab access
2kw solar / lithium-ion batteries
250 gallons fresh water
138 gallons diesel
Diesel heat/hot water
6kw cummins onan quiet diesel generator
Airhead composting toilet, full dry shower
AS BUILT- $292,000
APEX 6x6 SPECS
DIMENSIONS
Length: 28’ 10"


Height: 12’ 2”


Width: 8’ 2”


Wheelbase: 13’ 5”
Engine Caterpillar 3126 6 cylinder , fuel injected , turbocharged and after cooled 290 HP diesel
Torque 738 ft,lb
Transmission Allison 3070 - automatic 7 speed , with Full time AWD
Electrical System 12/24V 100 amp Alternator
Brakes Air Actuated
Max speed 74MPH ( as equipped with high speed gearing)
Range 800+ miles
Max speed 74MPH ( as equipped with high speed gearing)
Central tire inflation system Dana/Eaton
Recovery winch 20,000 lb
Ground clearance 22"
BASE OPTIONS
Standard
Hunter RMV sourced low-mileage and refurbished x-Military LMTV/ MTV
Upgrade
Acela fully refurbished x-Military LMTV
+$60,000 - $100,000
Go Anywhere, and Tow Anything
Set up with off-roading to remote places in mind, its massive 4-point articulating subframe allows extreme flexibility. Its central tire inflation system, 20,000 lb recovery winch, and optional sand ladders ensure maximum terrain ability. In original configuration, this 6x6 BAE truck had a GVWR of over 70,000 with the ability to tow 40' trailer. Now considerably improved, it retains a huge towing ability, so hook up!
every detail accounted for
Freedom means you have choices. Built to Milspec standards and sporting a massive 4 point articulating sub-frame, the Apex - Line 6x6 comes with an air-conditioned cab, Scheel - Mann Vario F seats, cruise control, Garmin Overlander GPS, reverse camera, high speed gearing, 138 gallons fuel tankage, comprehensive LED lighting, and a 20,000 lb recovery winch.

Apex is equipped with 2kw solar, li-on batteries, a 6kw Diesel generator, meaning you will have all the power you need (and hookups just in case you venture into an RV park!)

It has a water filtration system, diesel hot water/ heat, and a highly efficient mini-split air conditioning system with heat pump, all contained in a luxurious highly insulated thermal habitat box.

250 gallons of fresh water means you can venture far and survive in comfort with a king size bed– plus a dinette bed for 1 or 2, leather seating, well-equipped kitchen with induction cooktop, microwave, fridge and freezer, and washer / dryer, all surrounded by beautiful solid alder cabinetry. And that's not all– an HD TV, a dry bath with tiled shower, and an Airhead state of the art composting toilet means life in the wilds need not be!
Luxuries, necessities, bells, whistles
Aux LED Lighting
Cab for 3 with Scheel-Mann Vario F seats
Cruise Control
Garmin Overlander GPS
LED lighting + reverse camera
High speed gearing (74 mph)
Clear source filtration system
Storage boxes and Roof baskets
King bed + 1 double
Splendide Platinum washer/dryer
Isotherm fridge/freezer
Induction cooktop
Microwave
Hidden safe
Smart TV/DVD system
Aqua Hot diesel heat/water
9000 BTU Pioneer High Seer A/C - heat
Full dry bath/tiled shower
High-quality, solid wood, superior alder custom cabinetry
Granite counter tops
Stainless steel appliances and sink
Articulating stairs and entry platform
LP BBQ
OPTIONS
16' awning
Hydra Lift m/cycle (electric bike or side by side)
Upgraded A/V system
Sand ladders
GOTTA HAVE IT?
Or just have some questions about it?
To order your Apex, or to get your questions answered, just get in touch.
CONTACT US
